HINOTEK NK-106 Biological Microscope (Monocular)

Viewing Head: 45° 45° inclined monocular

Eyepiece: WF10X (options: WF16X; WF10X 0.1mm + WF10X cross scaled 0.1mm)

Objective: DIN 4X / 10X / 100X (S) DIN achromatic objective

Nosepiece: Triple Nosepiece

Stage: 110 x 120mm Simple platform

Focusing: Coarse fine tuning separate focusing mechanism; ( options: 0.002MM Coaxial Coarse Fine Focus Adjustment System)

Condenser: NA0.65 5 hole dial light blue NA0.65 single condenser (options)

Illumination: Flat-concave reflector (options: 110V / 22V 6V20W Adjustable brightness )

Camera Interface: “C” Standard port
