Haz-Dust HIM-6000 Environmental Perimeter Air Station

- Lung Damaging Particulates: TSP& PM-10 or PM-2.5, PM-1.0, or Respirable (PM-4.0) (include)
- Temperature (include)
- Relative Humidity (include)
- CO (0-10ppm) (include)
- NO₂ (0-5ppm) (include)
Option add upto 12 sensors:
- Particulates
+ Particulates 90º Infra Red Light Scattering 1 - 20,000µg/m3 OR 0.01 – 200mg/m3 (optional)
+ Particle Size Range: 0.1 - 100µm
+ Particle Size Measurement
* 1µm, 2.5µm, 4.0µm(OPTIONAL),
* 10µm, TSP (STANDARD)
- Volatile Organics (VOC) (HIM-6000 Sensors)
+ PID 10.6 ev: 0 – 50,000 ppb (0-50 ppm)
- Carbon Dioxide (HIM-6000 Sensors)
+ NDIR 0 – 5,000 ppm (optional)
- Toxic Gases (Electrochemical) (HIM-6000 Sensors)
+ CO – Carbon Monoxide 0 – 10,000 ppb (0-10ppm)
+ CH-4 Methane 0 to 100% Vol. (optional)
+ Hydrocarbons: specify gas type when ordering
+ NO2 – Nitrogen Dioxide 0 – 5000 ppb (0-5ppm ) (optional)
+ SO2-Sulfur Dioxide 0 to 5000 ppb (0 to 5 ppm) (optional)
- Other Parameters (HIM-6000 Meters)
+ Rain Gauge (heated, tipping bucket): 0 to 5 inches (optional)
+ Temperature: -4 to 140 F (-20ºC to 60ºC) (standard)
+ Solar Irradiance: 0-111 watts per square meter (w/m²) (optional)
+ Sound & Noise: 30 – 135 db (optional)
+ Atomic Radiation: 1 – 19,999cpm or 0.001 to 100 miliRad/hr (optional)
+ ELF Radiation: 1 – 200mG (optional)
+ Wind Speed/Direction: 0-125mph / 5-355deg (standard)
+ Barometric Pressure: 28-31 inches/Hg (optional)
+ Dew Point Temperature /Wet Bulb Temperature
* -47.2 to 122 F (-44 to 50 C)
* 3.2 to 122F (-16 to 50 C) (optional-one meter)
- Tripod stand optional

Instrument Specifications:
Display LCD real time
Operation: 4 Key Splash Proof Membrane Switch
Power 12V Battery
Operating Time: 10 Hours on Standard Battery
Continuous on AC, Optional Solar Panels
