GW INSTEK LCR-1100 Handheld LCR Meter
ManufacturerGW INSTEK(View more products from this manufacturer)
ModelLCR-1100
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Test Frequency: 50/100/120Hz/1k/2k/10k/50k/100kHz
Display: Primary / Secondary: 50.000 counts
Output Impedance: 100Ω
Basic Accuracy: 0.2%
Test Speed: Slow: 2,5 times/s, Fast: 10 times/s
Test Signal Level: 0.3V/0.7V/1.0 Vrms selectable
Tesst Parameters: CD, CQ, CR, LD, LQ, LR, L-Rdc, RQ, RX, R-Rdc, Rdc, ZD, ZQ, Z-θr, Z-θd
Equivalent Circuit: Series / Parallel selectable
