AC WITHSTANDING
Output-Voltage Range:0.100kV~ 5.000kV ac
Output-Voltage Resolution:2V/step
Output-Voltage Accuracy:± (1% of setting +5V) [no load]
Maximum Rated Load:200 VA (5kV/40mA)
Maximum Rated Current:40mA (0.5kV < V ≦ 5kV); 10mA (0.1kV ≦ V≦ 0.5kV)
Output-Voltage Waveform:Sine wave
Output-Voltage Frequency:50 Hz / 60 Hz selectable
Voltage regulation:± (1% of reading +5V) [full load → no load]
Voltmeter Accuracy:± (1% of reading+ 5V)
Current Measurement Range:0.001mA~040.0mA
Current Best Resolution:0.001mA / 0.01mA / 0.1mA
AC Current Measurement Accuracy:±(1.5% of reading +30 counts) when HISET < 1.00mA; ±(1.5% of reading +3 counts) when HISET ≧ 1.00mA
Window Comparator Method:Yes
ARC Detect:Yes
RAMP (Ramp-Up Time):0.1~999.9s
TIMER (Test Time)*OFF, 0.5s~999.9s
GNDON/OFF
MEMORY
Single Step Memory:MANU : 100 blocks
Automatic Testing Memory:AUTO : 100 blocks, menu per auto : 16
INTERFACE
RS232:Standard
USB (Device):Standard
GPIB:Option
Remote Terminal (Front):Standard
SIGNAL IO:Standard
General
DISPLAY:240 x 64 dot matrix LED back light LCD
POWER SOURCE:AC100V/120V/220V/230V ±10%, 50/60Hz
POWER CONSUMPTION:500VA max.
DIMENSIONS & WEIGHT:330(W) x 148(H) x 452(D) mm (Max.), approx.19kg(Max)
