Gw instek GDM-8145 50,000 Counts Dual Display Digital Multimeter
ManufacturerGW INSTEK(View more products from this manufacturer)
ModelGDM-8145
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
| DC VOLTAGE | |
| Range | 200mV, 2V, 20V, 200V, 1000V 5 ranges |
| Accuracy | +(0.03% rdg + 4 digits) |
| Input Impedance | 10MΩ |
| AC VOLTAGE (AC or AC + DC True RMS) | |
| Range | 200mV, 2V, 20V, 200V, 1000V 5 ranges |
| Accuracy | 200mV ~ 200V 4 ranges 20Hz ~ 45Hz: +(1% rdg + 15 digits) 45Hz ~ 2kHz: +(0.5% rdg + 15 digits) 2kHz ~ 10kHz: +(1% rdg + 15 digits) 10kHz ~ 20kHz: +(2% rdg + 30 digits) 20kHz ~ 50kHz: +(5% rdg + 30 digits) 1000V range 45Hz ~ 1kHz: +(0.5% rdg + 15 digits) |
| Input Impedance | 10MΩ |
| DC CURRENT | |
| Range | 200μA, 2mA, 20mA, 200mA, 2000mA, 20A 6 ranges |
| Accuracy | 200μA ~ 200mA 4 ranges+(0.2% rdg + 2 digits) 2000mA ~ 20A 2 ranges+(0.3% rdg + 2 digits) |
| AC CURRENT | |
| Range | 200μA, 2mA, 20mA, 200mA, 2000mA, 20A 6 ranges |
| Accuracy | 200μA ~ 200mA 4 ranges 45Hz ~ 2kHz: +(0.5% rdg + 15 digits) 2kHz ~ 10kHz: +(1% rdg + 15 digits) 10kHz ~ 20kHz: +(2% rdg + 15 digits) 2000mA ~ 20A 2 ranges: 45Hz ~ 2kHz：+(0.5% rdg + 15 digits) |
| RESISTANCE | |
| Range | 200Ω, 2kΩ, 20kΩ, 200kΩ, 2000kΩ, 20MΩ 6 ranges |
| Accuracy | 200Ω range+(0.1% rdg + 4 digits) 2kΩ~ 2000kΩ 4 ranges+(0.1% rdg + 2 digits) 20MΩ range+(0.25% rdg + 2 digits) |
| DIODE TEST | |
| Test Current | Max. 1mA |
| Open Voltage | Max. 13V |
| DISPLAY | |
| 0.5" LED Display | |
| POWER SOURCE | |
| AC 100V/120V/220V/230V +10%, 50/60Hz | |
| DIMENSIONS & WEIGHT | |
| 230(W) × 95(H) × 280(D) mm Approx. 2kg | |
.
Discontinuous.
