GW INSTEK GBM-3100H Battery Meter (1000V, 3.2kΩ)

AC resistance: 0~3.2kΩ

DC voltage: 0~1000V

DISPLAY

Screen: 3.5”(320 x240) TFT LCD

Resistance :5 digits

Voltage: 6 digits

TEST SPEED

Speed: 4 time/second

Medium: 11 time/second

Fast: 25 time/second

Ex. Fast: 60 time/second

RESISTANCE MEASUREMENT

Test frequency: 1kHz (±0.5Hz) Fixed

Imput impedance: 3mΩ ~ 300mΩ : 99kΩ, 3Ω ~ 3kΩ : 2MΩ

Range: 3mΩ ~ 3kΩ

VOLTAGE MEASUREMENT

Range: 10 ~1000V

OTHER FUNCTIONS

Range Selection: Auto range, Hold range, Nom range

Comparator: ABS, PER or SEQ

Contact detection: OPEN & WIRE

Buzzer: OFF, Pass, Fail

Trigger: INT, EXT

INTERFACE: USB Host / USB Device / RS-232C / Handler

POWER SOURCE: AC 100-240, 50-60Hz; Consumption: 10W

DIMENSIONS & WEIGHT: 264(W) x 107(H) x 309(D) mm, Approx. 2.8kg
