Grandwaytelecom FHP2B04 Optical Power Meter (-50~+26dBm, 800~1700nm)

Sensor Type: InGaAs

Working Wavelength: 800~1700nm

Calibrated Wavelength:

Standard: 850/1300/1310/1490/1550/1625nm

Optional: 980nm/1270nm/1577nm/1650nm,etc

Test Range: −50~+26dBm

Accuracy: ±0.2dB

Resolution: 0.01

Frequency Detection: 270Hz/330Hz/1kHz/2kHz

Recognizable Wavelength: 850/1300/1310/1490/1550/1625nm (with FHS2 series laser source)

Frequency Identification Range: −20dBm~+26dBm@1550nm

Wavelength Identification Range: −20dBm~+26dBm@1550nm

Unit display: dBm/dB/mw

VFL(Optional):

Working wavelength: 650±10nm

Output power: 10mW

Working mode: CW/2Hz

Bluetooth(Optional): Can be connected with Android mobile phone software through Bluetooth

Memory Capacity: 999 groups (can be transferred to PC software and generate report)

USB Port: TYPE-C charging/data port

Power Supply: 2 Ni-MH AA battery | Input: AC100~240V, 50/60Hz Output: DC5V/1A

Working Temp: −10℃~+50℃

Storage Temp: −20℃~+70℃

Dimension/Weight: 160L×76W×45H(mm) / 265g

Accessories: 2*Ni-MH AA battery, FC adapter, SC adapter, Power adapter, USB cable, Test report, Quick guide, Carrying bag
