Gossen Metrawatt SYSKON P4500-060-180 Programmable DC Power Supply (4500 W, 60 V, 180 A)

Output Power: Up to 4500 W

Output Voltage Range: 0 – 60 V

Output Current Range: 0 – 180 A

Input Voltage: 115 / 230 Vac (wide-range, PFC supported)

Input Frequency: 47 – 63 Hz

Programming & Control: Analog & digital programmable, ultra-fast response (<2 ms)

Resolution: Voltage: 1 mV - Current: 1 mA

Accuracy: High precision: ≤0.05% + offset

Dynamic Performance: Excellent transient response, suitable for fast load & automotive simulation

Ripple & Noise: Low ripple output (precision testing applications)

Memory & Sequences:

Up to 1700 programmable sequence steps

15 preset memory configurations

Interfaces: USB, RS232 (standard), GPIB (optional), analog interface

Additional Functions:

Sense terminals

Dynamic sink operation (~195 W)

Master-slave capability (parallel/series operation)

Protection: OVP, OCP, OTP, short circuit protection

Applications: Automotive, endurance testing, production testing, system integration

Dimensions (W × H × D): ~447 × 191 × 541 mm

Weight: ~20 kg
