Gossen Metrawatt METRAHIT IM TECH BT Low Resistance Measurement (1000 V AC/DC; 200 mA / 1 A)

Display: 3.5" color TFT LCD, 30,000 counts (320 × 480 px)

Measurement Functions: AC/DC voltage, AC/DC current, resistance, low-resistance (4-wire Kelvin), continuity, frequency, capacitance, temperature (RTD & K-type), diode test

Low-Resistance Measurement: 4-wire Kelvin, test current 200 mA / 1 A, resolution down to 1 µΩ

Voltage Range: Up to 1000 V AC/DC

True RMS Bandwidth: Up to 100 kHz

Data Logger: Internal memory up to 300,000 values, real-time clock

Interfaces: Bluetooth (BT), USB (optional power module)

Wireless App: METRALOG App (Android), IZYTRON.IQ PC software

Protection Class: IP52

Safety Category: CAT III 1000 V / CAT IV 600 V

Power Supply: Li-ion rechargeable battery + optional mains module

Operating Temperature: -10°C to +50°C

Dimensions (L × W × H): approx. 190 × 87 × 52 mm

Weight: approx. 0.6 kg (with battery)
