Gossen Metrawatt KE7010 Remote Unit (KE7100 and KE7200)

Function:

Active remote unit with microprocessor

Pass/Fail indication with green LED

ID freely programmable from 1-32 (at most 32 KE7010 units can be managed and used by the KE7200)

Connection: RJ-45 socket

Housing: Stable, impact-resistant ABS housing

Dimensions: 78 × 45 mm

Weight: 30 g

Power Supply: Via RJ-45

Operation Environment:

Working temperature: 0 °C … +50 °C

Storage temperature: –25 °C … +75 °C

Humidity: 90%, non-condensing
