GIGAHERTZ SOLUTIONS Safe & Sound Pro II RF Analyzer (200 MHz - 8 GHz; 400 MHz - 7.2 GHz)

Item weight: 0.30 kg

Frequency range:

Effective measurement range: 200 MHz - 8 GHz

"True Response" detection range: 400 MHz - 7.2 GHz

Scope of delivery:

Safe & Sound Pro II meter

Zipper carry pouch

User instructions

Measurement range:

(manufacturer information): down to 0.001 µW/m²; upper end (spec-dependent) up to 3,180,000 µW/m²

Precision: Accuracy: +/- 6 dB, 3rd-party tested/certified

Sensor: Integrated antenna

Audio analysis: Audio function for source orientation + multiple volume levels + audio on/off

Signal rating:

Green (blinking): < 1 µW/m²

Green: 10 µW/m²

Yellow: 10 - 100 µW/m²

Orange: 100 - 1,000 µW/m²

Red: 1,000 - 10,000 µW/m²

Red (slow blinking): 10,000 - 100,000 µW/m²

Red (fast blinking): > 100,000 µW/m²

Power supply:

Power: 2x AA batteries (included depending on version/offer)

Datasheet

Manual
