GIGAHERTZ SOLUTIONS ME3840B LF Analyser (5 Hz - 100 KHz)

Item weight: 0.40 kg

Frequency range:

5 Hz - 100 KHz (compensated, better than -2 dB).

Internal switchable frequency filter: 16 Hz bandpass, 50 Hz highpass, 2 kHz highpass for building biology analysis to identify railroad and mains current as well as higher frequency harmonics.

Scope of delivery:

Measuring device

Grounding cable

Alkaline manganese battery

Detailed instruction manual with neutral Background information

Measurement range:

Magnetic flux density (one-dimensional): 1 - 1999 nT

Electric field strength: 1 - 1999 V/m

Precision: +/- 2 %, +/- 14 digits @ 50/60 Hz

Sensor:

E-field sensor for electric LF alternating fields

H-field sensor for magnetic LF alternating fields (one-dimensional)

Audio analysis:

Sound signal proportional to field strength (with "Geiger counter effect", switchable)

Signal rating: RMS

Power supply:

9-volt E-block alkaline manganese battery (included), average operating time: 24 to 36 hours (depending on operating mode)

Low-Batt. indicator

Auto power-off function

Manual
