GIGAHERTZ SOLUTIONS HFW35C RF Analyzer (2.4 GHz - 6 GHz)

Item weight: 0.41 kg

Frequency range: 2.4 GHz - 6 GHz

Scope of delivery:

Measuring device

Plug-on LogPer antenna with antenna cable

Alkaline manganese battery

Detailed operating instructions with neutral background information

Measurement range: Power flux density: 0.1 - 1999 µW/m²

Precision:

Basic accuracy (CW) including linearity error: +/- 6 dB

Zero point deviation and special digitizing error ("rollover"): +/- 9 digits

Sensor:

Optimized logarithmic-periodic measuring antenna with frequency response compensated directly on the antenna and very good directionality (patent under examination AZ 10 2006 051 180.8)

Audio analysis:

Modulation frequency and field strength proportional audio signal supports identification of pulsed radiation sources (WLAN, WiFi, etc.) and detection of elevated exposures.

Signal rating:

Peak value and average value display.

Quantitative differentiation of pulsed and unpulsed radiation (patented circuit).

Power supply:

9-volt E-block alkaline manganese battery (included), average operating time: 6 - 7 hours (depending on operating mode)

Low-battery indicator

Auto power-off function
