GIGAHERTZ SOLUTIONS HF38B RF Analyzer (700 MHz - 2.7 GHz)

Item weight: 0.50 kg

Frequency range: 700 MHz - 2.7 GHz (3.3 GHz with increased tolerances)

Scope of delivery:

Measuring device

Plug-on LogPer antenna with antenna cable

Alkaline manganese battery

Detailed operating instructions with neutral background information

Measurement range: Power flux density: 0.01 - 19,990 µW/m²

Precision:

Basic accuracy (CW) including linearity error: +/- 6 dB

Zero point deviation and special digitizing error ("rollover"): +/- 9 digits

Sensor:

Optimized log-periodic measuring antenna: lower ripple, lower bearing deviation, improved downward shielding

Audio analysis:

Modulation frequency and field strength proportional audio signal supports identification of pulsed radiation sources (GSM, DECT, etc.) and detection of elevated exposures.

Signal rating: Peak & average value display and peak hold

Power supply:

9-volt E-block alkaline manganese battery (included), average operating time: 6 - 7 hours (depending on operating mode)

Low-battery indicator

Auto power-off function
