GIGAHERTZ SOLUTIONS HF38B-W RF Analyser Kit (700 MHz - 6 GHz)

Item weight: 1.90 kg

Frequency range: 700 MHz - 6 GHz

HFW35C: 2.4 GHz - 6 GHz

HF38B: 700 MHz - 2.7 GHz

Measurement range: Power flux density: 0.01 - 19,990 µW/m²

HFW35C: Power flux density: 0.1 - 1999 µW/m²

HF38B: Power flux density: 0.01 - 19,990 µW/m²

Precision:

Basic accuracy (CW) including linearity error: +/- 6 dB

Zero point deviation and special digitizing error ("rollover"): +/- 9 digits

Sensor: Logarithmic-periodic measuring antennas

Audio analysis:

Modulation frequency and field strength proportional audio signal supports identification of pulsed radiation sources (GSM, DECT, etc.) and detection of elevated exposures.

Signal rating:

Peak & average display and with the HF38B peak hold ("Peak Hold").

Power supply:

9-Volt E-block alkaline manganese batteries (included), average operating time: 6 - 7 hours (depending on operating mode)

Low-Batt. indicator

Auto power-off function

Manual HFW35C

Manual HF38B
