GESTER GT-KC21 Water Vapor Permeability Tester

Test water vapor permeability for vamp and upper shoe materials (including surface and lining)

Testing condition:

Temperature: (23 ± 2)°C

Humidity: (50 ± 5)% RH

Testing bottle number: 6pcs

Bottle mouth diameter: 30mm

Bottles holder speed: 75 ±5cpm

Fan blades: 90 x 75 mm, 3 flat blades in planes inclined at 120° to each other

Fan rotate speed: (1400 ± 100) r/min

Specimen size: ￠34mm

Control system: Programmable Microprocessor Control

Temperature range:0~100℃

Humidity range: 20%～98%RH

Power supply: 1∮AC220V 50/60HZ

Standards:

EN ISO 20344 Section 6.6.2 and 6.8

AS/NZS 2210.2 Section 6.6.2 and 6.8

GB/T 20991 Section 6.6.2 and 6.8

EN 344-1 Section 5.13

Standard Accessories:

• Testing Bottles 6pcs

• Power Line 1pc
