GESTER GT-KC10C Low Temperature Flexing Tester for Footwear Upper

Types of Test Grips: Whole shoes flexing test grips; Upper flexing test grips; ROSS flexing test grips; Bally flexing test grips

Number of Position: 2Sets; 2Sets; 2Sets; 3Sets

Flexing Speed: 140cpm; 300cpm; 60cpm; 100cpm

Bending Speed: 0-90°(Adjustable); /; 90°; 22.5°

Counter: Touch Screen, 0-999,999.( Adjustment)

Control System: Touch Screen Programmable Microprocessor Control

Temperature Range: -40~100℃

Inside Chamber Capacity: 150L

Chamber Material: SUS # 304 Stainless Steel and Painted

Power Supply: 1∮AC220V 50/60HZ

Weight: 500kg

Accessories:

For whole shoes flexing test: 1set: Plastic pad; 1set: Heel clamp

For ROSS flexing test: 1pc: Chisel cutter (2mm)
