GESTER GT-KB05E Low Temperature ROSS Whole Sole Flexing Tester (90±2°, 0~110 cpm)

Determine right angle flexing resistance at low temperature for whole sole of rubber, PU, PVC, TPR foam and other materials.

Fixture: 3sets

Bending Angle: 90±2°

Bending Speed: 0~110 cpm (Can be adjustable.)

Winding Shaft Radius: 5±0.3mm

Specimen Dimension: Whole sole

Counter: LCD, 0~99,999,999

Control System: Touch Screen Programmable Microprocessor Control

Temperature Range: -40~100℃

Temperature Accuracy: +/-0.5℃

Inside Chamber Capacity: 150L

Chamber Material: SUS # 304 Stainless Steel and Painted

Power Supply: 1∮AC220V 50/60HZ

Dimension (W×D×H): 110X170X180 cm

Weight: About 400 kg

Datasheet
