GESTER GT-C47B Low Temperature Schildknecht Flex Fatigue Tester (498±24 rpm/min)
ManufacturerGESTER(View more products from this manufacturer)
ModelGT-C47B
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Clamps: 10Sets (stainless steel )
Rotate Speed: 8.3Hz±0.4Hz (498±24r/min)
External Diameter of the Cylinder: 25.4mm±0.1mm
Test Track: Arc-shaped, R460mm
Test Stroke: 11.7mm±0.35mm
Lathedog Width: 10mm±1mm
Inner Distance of the Lathedog: 36mm±1mm
Size of the Specimen: 50mm×105mm
Counter: LCD, 0 - 999,999.( Adjustment)
Temperature Control System: Programmable Microprocessor Control (Touch Screen)
Temperature range: -30~100℃
Power Supply: 1∮AC220V 50/60HZ
Weight: 300kg
Standard: ISO 7854, BS 3424: Part 9, GB/T 12586, EN 14325
