FUZRR FR2000B+ Clamp Ground Resistance Tester (0.01Ω-1200Ω)

Resistance range: 0.01Ω-1200Ω

Class type: Explosion proof type

Resistance resolution 0.001Ω

Current range: No

Current resolution: No

Function: Ground resistant test, Loop resistance test, leakage current test

Power: Supply 4 section AA alkaline dry battery

Clamp Diameter: 55mmx32mm

O+A Synchronized display: O+A same screen display

Display Mode: 4-digit LCD display, black screen design

LCD Dimension: 46mmx29mm

Meter Dimension W/T/H: 85mmx58mmx285mm

Sampling Speed: About 2 times/second

Data Review: "MR" symbol indication when reviewing data

Interference Test: Automatic identify interference signal,"NOISE"symbol indication when the interference current is large

Alarm Function: Alarm when the measured value exceeds the alarm setting value

Power Consumption: 50mA Max

Weight Instrument: 1180g (with battery)

Working Temperature and Humidity: -10°C~40°C; below 80% rh
