Performance Specifications and Features
Microphones: 16 high-precision MEMS sensors
Frequency band: 2kHz to 48kHz
Detection range: 0.50 m to 50 m (based on site conditions)
Field of view (H × V): 50° × 38°
Frame rate: 20 Hz
Sensitivity: -38 dBV
Signal-to-noise ratio: 73 dBA
Visible lens resolution: 2 MP
Acoustic image: SoundMap™ image
Quick leak detection mode:
Leak mode enabled: Frequency band locks at 37.4 kHz to 42.6 kHz
Leak mode disabled: Frequency band selection through manual slider
dB value of the target centerpoint: Yes, it can be enabled or disabled
Focal length: 50 cm to infinity
Image format: JPG, MP4 (up to 5 minutes)
Color palettes: 3: IronRed, Blue-Red and Grayscale
Palette: Color Blending: Yes, 0% ~ 100%
Customized watermark: Image or English character watermarks
General Specifications
Interface: Type-C
OS supported: Android / HarmonyOS
Operating temperature: 0 °C to +40 °C
Storage temperature: -30 °C to +60 °C
Operating humidity: 10% to 90% RH, non-condensing
Operating altitude: Up to 2000 m
Storage altitude: Up to 12000 m
Power consumption: 1.2 W (Typical)
Ingress protection: IEC 60529: IP54
Size (L × W × H): 61 × 50 × 12 mm
Weight: 50 g
