Nominal current range:10 A, AC/DC 100 A, AC/DC
Continuous current range:0.1 A - 10 A AC/DC; 1 A - 100 A AC/DC
Maximum non-destructive current:140 A - 2 kHz
Lowest measurable current:0.1 A
Basic accuracy:
100 mV/A setting: 50 mA to 10 A ±3% of reading +50 mA
10 mV/A setting: 50 mA to 40 A ±4% of reading +50 mA
40 A to 80 A ±12% of reading +50 mA
80 to 100 A ±15% of reading
Useable frequency:DC - 100 kHz
Output level(s):10 A range: 100 mV/A
100 A range: 10 mV/A
Zero error adjustment:Yes
Safety Specifications
Safety:CAT II, 600 V; CAT III, 300 V
Maximum voltage:600 V
Mechanical and General Specifications
Battery life:9 V, 55 h
Maximum conductor diameter:11.8 mm
Output cable length:1.6 m
BNC adapter:Yes
