FLUKE 5 Intrinsically Safe Mini Infrared Thermometer

- Temperature Range : -40 °C to 800 °C (-40 °F to 1472 °F)

- Display Resolution : 0.1 °C / 0.1 °F

- Accuracy : <0 °C: ±(1.0 °C + 0.1 °/1 °C) / <32 °F: ±2 °F ±0.1 °/1 °F

≥0 °C: ±1 % or ± 1.0 °C, whichever is greater / ≥32 °F: ±1 % or ±2 °F, whichever is greater

- Spectral Response: 8 μm to 14 μm

- Response Time : <500 ms

* KTC Input Range: -270 °C to 1372 °C (-454 °F to 2501 °F)

- KTC Resolution : 0.1 °C/0.1 °F

- KTC Input Accuracy : <-40 °C: ±(1 °C + 0.2 °/1 °C) / <-40 °F: ±(2 °F + 0.2 °/1 °F)

≥-40 °C: ±1 % or 1 °C, whichever is greater / ≥-40 °F: ±1 % or 2 °F, whichever is greater

- Distance : 50:1 (D:S)

- Laser sighting: Single laser

- Emissivity: Digitally adjustable from 0.10 to 1.00 by 0.01 or via built-in table of common materials

- Operating Temperature : 0 °C to 50 °C (32 °F to 122 °F)

- Storage Temperature : -20 °C to 60 °C (-4 °F to 149 °F)

- Power : 2 AAA /LR03 type-approved batteries.
