Flex Power Modules PUC2415D1B Isolated

Width: 7.1 mm (0.28 in)

Height: 11.5 mm (0.453 in)

Length: 19.7 mm (0.776 in)

Industry: Industrial

Compliance: EN/UL 62368-1

Output Power: 1 W

REACH - SVHC: Details

Mounting Style: Through Hole

Isolation Voltage: 6 kV

Number of Outputs: 2 Output

Input Voltage - Max: 26.4 V

Input Voltage - Min: 21.6 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 34 mA

Output Current-Channel 2: 34 mA

Output Voltage-Channel 1: 15 V

Output Voltage-Channel 2: - 15 V

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 40 C
