FCL Components JY-48HG-K Medium Load Control RELAY, POWER
ManufacturerFCL Components(View more products from this manufacturer)
ModelJY-48HG-K
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 9.8 mm
Height: 12.8 mm
Length: 20 mm
Coil Type: Non-Latching
Coil Current: 5 A
Coil Voltage: 48 VDC
Mounting Style: PCB Mount
Coil Resistance: 6.4 kOhms
Coil Termination: Solder Pin
Contact Material: Silver Cadmium
Power Consumption: 200 mW
Switching Voltage: 250 VAC, 150 VDC
Relay Contact Form: 1 Form A (SPST-NO)
Contact Termination: Solder Pin
Maximum Switching Current: 3 A
