Fairchild FFPF10UP20STU Ultra Fast Recovery Rectifiers 10A/200V UltraFast
ManufacturerFairchild(View more products from this manufacturer)
ModelFFPF10UP20STU
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 4.7 mm
Height: 9.19 mm
Length: 10.16 mm
Unit Weight: 2.565 g
REACH - SVHC: Details
Configuration: Single
Recovery Time: 35 ns
Mounting Style: Through Hole
Max Surge Current: 100 A
Termination Style: Through Hole
If - Forward Current: 10 A
Ir - Reverse Current: 100 uA
Vf - Forward Voltage: 1.15 V
Vr - Reverse Voltage: 200 V
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 65 C
