Extech MS6100 100MHz 2-Channel Digital Oscilloscopes

Oscilloscope Functions

Bandwidth: 100MHz

Sample rate: per channel 500MS/s

Risetime: 3.5ns

Timebase Range: 4ns/div đến 40s/div

Record Length: 1M points per channel

Display Size: 5.6" (142mm) color LCD; 640 x 480 pixels

Channels: 2

Vertical Sensitivity: 2mV/div to 5V/div

Vertical Resolution: 8 bits

Glitch Capture: Yes

Sample Mode: Normal, Average, Peak Detect

Trigger Modes: Edge, Pulse, Alt, Video, Slope

Trigger Source: CH1, CH2

Trigger Coupling: AC, DC, LF, HF, Noise Reduction

Input impedance: 1MΩ/20pF

Max Input Voltage: 300V (peak)

Cursor Measurement: Voltage and time; Delta (CH1-CH2)

True RMS MultiMeter Functions

AC Voltage: 60mV, 600mV, 6V, 60V, 600V

DC Voltage: 60mV, 600mV, 6V, 60V, 600V, 800V

AC/DC Current: 60mA, 600mA, 10A

Resistance: 600Ω, 6kΩ, 60kΩ, 600kΩ, 6MΩ, 60MΩ

Capacitance: 5nF to 400μF

Diode and Continuity: Yes

Power Supply: 3 hours Li-ion rechargeable battery; AC Charger

Dimensions/Weight: 9.6 x 6.4 x 2" (245 x 163 x 52mm) / 2.6lbs (1.2kg)

Complete with two 1X/10X oscilloscope probes, test leads, 7.4V Li-Ion battery, universal AC charger, and carrying case

Manufacture: Extech USA

Discontinued
