EXTECH MG325 Differential Pressure Manometer / Datalogger

Insulation Resistance

Range: 50MΩ, 100MΩ, 200MΩ,500MΩ, 2000MΩ, 1GΩ, 10GΩ, 20GΩ, 50GΩ, 100GΩ, 200GΩ

Resolution: 0.001MΩ

Basic Accuracy: 0.001MΩ

Insulation Test Voltages

Range: 50V, 100V, 250V, 500V, 1000V

Resolution: -

Basic Accuracy: 0 to 20%

AC/DC Voltage

Range: 600V

Resolution: 0.01V

Basic Accuracy: AC: ±(1.5%+5d)/ DC: ±(2%+3d)

Leakage Current

Range: 2000µA

Resolution: 10µA

Basic Accuracy: ±(10%+3d)

Resistance

Range: 10MΩ

Resolution: 0.01kΩ

Basic Accuracy: ±(3%+3d)

Low Resistance

Range: 100Ω

Resolution: 0.01Ω

Basic Accuracy: ±(1.5%+5d)

Capacitance

Range: 500µF

Resolution: 0.1nF

Basic Accuracy: ±(5%+5d)

Frequency

Range: 1kHZ

Resolution: 0.1HZ

Basic Accuracy: ±(0.1%+3d)

Continuity (audible):Yes

Dimensions/ Weight: 8.9 x 4.1 x 2.3" (225 x 103 x 59mm)/ 1.5lbs (0.7kg)
