EXTECH CM78 Clamp Meters with IR Thermometer (1000A, 1000V; True RMS; AC/DC; IR)

MAX Range /  BASIC ACCURACY

AC/DC current: 1000A / ±2.5%

AC/DC voltage: 1000V / ±1.5%

Resistance:  40.00MΩ / ±1.5%

Capacitance:  4.000mF / ±3%

Frequency:  4000Hz / ±1.5%

Temperature (IR): -20 to 518°F, -20 to 270°C / ±2%

IR distance to target ratio:  8 inches away : 1 inch spot size

Type K temperature (optional probe): -4 to 1400°F, -20 to 760°C / ±3%

Bluetooth range max:  32ft (10m)

Jaw opening: 1.7in (42mm, 1500MCM)

Category rating: CAT IV-600V, CAT III-1000V
