EXFO T200S-CL High-power continuously tunable laser (1500 - 1630nm)

Wavelength:

Wavelength range (nm) : 1500 - 1630

Wavelength uncertainty a (pm) : ±5 (typical); ±20

Wavelength repeatability b (pm) : ±5 (typical)

Wavelength stability c (pm): ±5

Wavelength resolution setting (pm): 1

Sweep control:

Maximum speed (nm/s) : 100 (200 optional)

Adjustable speed (nm/s) : 0.5, 1, 2, 5, 10, 20, 50, 100 (200 optional)

Mode-hop-free operation : Active mode-hop cancellation

Minimum wavelength sweep trigger resolution (pm) : 0.5

Optical power Nominal output power over full wavelength range (dBm) : 10

Power stability c (dB) : ±0.01 (typical)

Spectral characteristics:

Linewidth d (10 µs integration time) (kHz) : < 25 (typical)

Linewidth d (100 µs integration time) (kHz) : < 250 (typical)

Side mode suppression ratio e (SMSR) (dB) : > 50 (typical)

Signal-to-source spontaneous emission ratio f (SSSER) (dB) : 90 (typical)

Signal-to-total-source spontaneous emission ratio g (STSSER) (dB) : 75 (typical)

Relative intensity noise (RIN) (dB/Hz): –150 (typical)

Optical output Optical fiber type: PM optical fiber, FC/APC connector

PER (dB) : 17 (typical)

SPECIFICATIONS – HARDWARE:

Environmental conditions:

Operating temperature : 15 °C to 35 °C (59 °F to 95 °F)

Operating humidity: < 80% (non-condensing)

SPECIFICATIONS – HARDWARE:

Environmental conditions:

Operating temperature : 15 °C to 35 °C (59 °F to 95 °F)

Operating humidity : < 80% (non-condensing)

Warm-up time (hour) : 1

Physical footprint:

Size (L x H x D): 217 mm x 173 mm x 441 mm (8 9/16 in x 6 13/16 in x 17 3/8 in)

Weight : 9 kg (20 lb)

Connectivity:

Monitor : 7 in capacitive touchscreen

Remote communication : Ethernet RJ45 LAN 10/100/1000 Mbit/s

Electrical BNC ports : 1x trigger IN, 1x trigger OUT, power monitoring and wavelength monitoring
