EXFO FLS-140 Visual fault locator (650 to 660 nm)

SPECIFICATIONS a

Operation (Hz): 2 to 3

Wavelength (nm) (typical: 650 to 660

Emitter type: Laser

Power output b (typical) (mW): 0.6

Maximum power output b (mW): <1

Distance range c (typical) (km): 5

Operation mode Pulsed and: CW

GENERAL SPECIFICATIONS

Power supply: 2 AAA alkaline batteries

Laser class: 2M

Battery life d (h) Pulsed: 40

Length: 157 mm (6 3/16 in)

Maximum diameter: 12 mm (1/2 in)

Weight (with batteries): 70 g (2.5 oz)

Temperature

Operating: —10 °C to 45 °C (14 °F to 113 °F)

Storage: —30 °C to 60 °C (—22 °F to 140 °F)
