Moving Area(X/Y/Z/R): 500 / 500 / 100 mm /±360°
Max. Speed: XY/Z：400 / 250 mm/sec R：720°/sec
Data Memory capacity: 9999 points/prog. 100 programs
Display: Teach Pendant LCD
Teaching Method: Teach Pendant
Temp. Control Power: 150 W
Solder Feeder System: Stepping Motor
Air Pressure: 5~7 kg/cm²
Working Temp.: 10-40°C
Dimensions WxDxH: 805 x 656 x 970 mm
Working Area(X/Y): 450(X1 :200, X2:200) / 500 mm
Repeatability: +/- 0.01 mm/ Axis
Program System: CF Card / USB
Drive System/ Stepping Motor: Micro Stepping Motor
Max.Temperature: Max. 500°C
Solder Wire Diameters: ø 0.4 ~ 1.2 mm
Clean System: Brush
Power Supply: 100V~230V/450W
Working Humidity: 20-85% no condensation
Weight: 60 kg
