ESS Technology ES9017S HyperStream IV 32-bit High-Performance 8-Channel DAC

Shutdown: Shutdown

Resolution: 32 bit

Interface Type: I2C, SPI

Mounting Style: SMD/SMT

Number of DACs: 8 DAC

Reference Type: Supply

THD plus Noise: - 110 dB

Dynamic Range dB: 126 dB

Power Consumption: 101.2 mW

Moisture Sensitive: Yes

Number of Channels: 8 Channel

Number of Converters: 8 Converter

Supply Voltage - Max: 1.2 V

Supply Voltage - Min: 1.2 V

Number of DAC Outputs: 8 Output

Operating Supply Current: 15.6 mA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 20 C
