DOF: 12 (6+6)
Arm Reach: 570mm per arm
Total Span: 1500mm
Weight: 1.5kg
Power Supply: 8.4V, 2A
Rotation Range: ±180°
USB Connection: Type-C
LCD Display: 2.0″ @ 320×240, IPS panel, 853 nits max brightness
Data Rate: Up to 100Hz
Main Controller: ESP32 (Basic), 240MHz dual-core, 600 DMIPS, 520KB SRAM, dual-mode Bluetooth and Wi-Fi
Auxiliary Controller: ESP32 ×2 (Atom), 4MB Flash, 5×5 LED Matrix
Interfaces: Provides access to joint position, speed, acceleration, button status, joystick state, gyroscope data, and customizable LED colors (read/write)
File Formats: Supports 3D-Step and 2D CAD files
Current Position: Read
Current Speed: Read
Current Acceleration: Read
Button Status: Read
Joystick State: Read
Gyroscope Data: Read
LED Light Color: Read/Write
Robot Compatibility: myCobot 280
myCobot 280 myCobot 320
myCobot 320 myCobot Pro 630
myCobot Pro 630 Mercury Humanoid Robot
Mercury Humanoid Robot myAGV
myAGV mechArm 270
mechArm 270 myBuddy 280
myBuddy 280 myArm M750
myArm M750 Other general-purpose robots
Other general-purpose robots
