Display: PS TFT Display; 240 x 363 dot matrix
Thermocouple Inputs (Up To 20)
K, T, J, E, N, R, S & B
%RH: ECD VaporWATCH® RH sensor
Data Acquisition
Sampling interval: 20 samples/second to 10 minutes/sample
Data points: 16 million or 200 data runs (whichever comes first
Accuracy: +/- 0.5°C (0.9°F)
Resolution: 0.0056°C (0.01°F)*
Noise rejection: 50-60 Hz*
Measurement range: -200°C to 1,200°C (-328°F to 2,192°F)
Power
Battery: LiPo (lithium polymer ion) - rechargeable, 1100mAh
Charger input current: 60 ma via USB interface
Communications
Interface: USB 2.0 compliant (charge;upload;download)
Cable: USB type A to USB-C, 1m (3’)
Dimensions (L x W x H):
Profiler: 410mm (16.14”) x 89mm (3.5”) x 9.41mm (0.37”)
Barrier: 476.3mm (18.75”) x 104mm (4.1”) x 26.9mm (1.06”)
Yellow Jacket: 480.6mm (18.92”) x 115mm (4.53”) x 32.5 (1.28”)
Weight:
Profiler: 0.386 kg (13.6 oz)
Barrier: 1.429 kg (3.15 lb)
Yellow Jacket: 1.113 kg (4.0 oz)
Operational range (profiler): -40°C to +85°C (-40°F to 185°F)
Humidity: 0-85% RH (non condensing)
