Display: PS TFT Display; 240 x 400 Dot Matrix
Thermocouple Sensors (Up To 12):
ECD micro-thermocouples: Type K*, T, J, E, N, R, S & B
%RH: ECD VaporWATCH® RH Sensor
*Type K: Special Limits of error ±1.1 or ±0.004*T per ASTM E230/E230M-12, IEC 60584:2013 and ISA–MC96.1–1982.
Data Acquisition:
Sampling Interval: 50 samples/second to 10 minutes/sample
Data points: 16 million or 200 data runs (whichever comes first)
Accuracy: +/- 0.5°C (0.9°F)
Resolution: 0.0056°C (0.01°F)*
Noise Rejection: 50-60 hrz*
Measurement range: -200°C to 1,200°C (-328°F to 2,192°F)
*>= 0.05 seconds/sample
Power:
Battery: LiPo (Lithium Polymer ion) – Rechargeable, 1100mAh
Charge Protection: optimized for lithium polymer
Charger input current: 60 ma via USB Interface
Physical:
Dimensions (L x W x H):
Profiler: 350.8mm (13.81”) x 89mm (3.5”) x 9.41mm (0.37”)
Barrier: 412.8mm (16.25”) x 104mm (4.1”) x 26.9mm (1.06”)
Yellow Jacket: 423.4mm (16.7”) x 115mm (4.53”) x 32.5 (1.28”)
Weight:
Profiler: 0.386 kg (13.6 oz)
Barrier: 1.202 kg (2.65 lb)
Yellow Jacket: 1.113 kg (4.0 oz)
Operational range (Profiler): -40°C to +80°C (-40°F to 176°F)
Humidity: 0-85% RH (Non Condensing)
Communications:
Interface: USB 2.0 Compliant (charge; upload; download)
Cable: USB Type A to USB-C, 1m (3’)
