Test Force:
1. Kgf: 0.2kgf, 0.3kgf, 0.5kgf, 1kgf, 2kgf, 2.5kgf, 3kgf, 5kgf, 10kgf
2. N: 1.96N, 2.94N, 4.90N, 9.80N, 19.6N, 24.5N, 29.4N, 49N, 98N
Test Range:1HV~2967HV
Loading Method:Automatic (Loading/Dwell/Unloading)
Turret:Automatic Shifting turret
Computer:CPU: Intel I3, Memory: 2G, SSD: 32G
CCD Pixel:1.30 Million
Conversion Scale:HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS, HBW
Hardness Reading:Indentation Displaying and Automatic Measuring on Touch Screen
Data Output:WORD or EXCEL Report with Curve Chart
Objective:10× ，20× ，40×
Total Magnification:100× ，200× ，400×
Resolution:0.25μm，0.125μm，0.0625μm
Dwell Time:0~60s
Light Source:Halogen Lamp
Motorized X-Y Test Table:Size: 100×100mm; Travel: 25×25mm; Resolution: 0.01mm
Max. Height of Specimen185mm
Throat:130mm
Power Supply:AC220V，50Hz
Execute Standard:ISO 6507，ASTM E92，JIS Z2244，GB/T 4340.2
Dimension:560×335×675mm，
Packing Dimension: 650×380×960mm
Weight:Net Weight: 48kg，Gross Weight: 62kg
