Control Mode:Manual / Automatic, three axis linkage, 10 inch touch screen control, Can be switched to the operating handle wheel
Feature:Automatic drain system, alarm system, double LED lighting, red laser positioning
Feeding Speed:3mm/min, 5mm/min, 8mm/min, 12mm/min (users may modify the set speed according to requirement)
Cutting Disc Size:Φ380×2.8×Φ32 mm
Work Table Dimension (X*Y):450×350 mm
Y axis Maximum Travel Distance:250 mm
X axis Maximum Travel Distance:100 mm
Z axis Maximum Travel Distance: 160 mm
Max. Cutting Section:120×100 mm
Fixture Caliber:120 mm
Frequency Conversion Motor:5.5kw, Rotating speed: 500-2800 r/min
Feeding Motor:Servo motor
Volume of the Water Tank: 120L
Dimensions:1400×1000×1850mm
Weight:1800kg
Cutting Disc Size:Φ400×3×Φ32 mm
Work Table Dimension (X*Y): 485×400 mm
Y axis Maximum Travel Distance:300 mm
X axis Maximum Travel Distance:100 mm
Z axis Maximum Travel Distance:230 mm
Max. Cutting Section:200x 120 mm
Fixture Caliber:200 mm
Frequency Conversion Motor:7.5kw, Rotating speed: 500-2800 r/min
Feeding Motor:Servo motor
Volume of the Water Tank: 120L
Dimensions:1550×1100×1900mm
Weight:2200kg
Cutting Disc Size:Φ400×3×Φ32 mm
Work Table Dimension (X*Y):530×630 mm
Y axis Maximum Travel Distance:420 mm
X axis Maximum Travel Distance:110 mm
Z axis Maximum Travel Distance:230 mm
Max. Cutting Section:300×150 mm
Fixture Caliber: 300 mm
Frequency Conversion Motor:7.5kw, Rotating speed: 500-2800 r/min
Feeding Motor:Servo motor
Volume of the Water Tank: 120L
Dimensions: 1650×1350×1900mm
Weight:2500kg
