Eaton EM912816 Fixed Terminal Blocks EUROMAG EM9128 SERIES, 16 POLE
ManufacturerEaton(View more products from this manufacturer)
ModelEM912816
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Pitch: 6.35 mm
Height: 21.7 mm
Length: 101.6 mm
Current Rating: 30 A
Mounting Angle: Straight
Mounting Style: PCB Mount
Voltage Rating: 300 V
Wire Gauge Max: 10 AWG
Wire Gauge Min: 24 AWG
Contact Plating: Tin
Contact Material: Brass
Housing Material: Thermoplastic (TP)
Connection Method: Spring Cage, Screw
Termination Style: Through Hole
Flammability Rating: UL 94 V-0
Number of Positions: 16 Position
