Eaton E52Q-DL15UAE01 Proximity Sensors INDUCTIVE PROX,15MM UN,1NO/1NC,MINI
ManufacturerEaton(View more products from this manufacturer)
ModelE52Q-DL15UAE01
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 2.73 in
Height: 1.57 in
Length: 1.57 in
Unit Weight: 243.806 g
Mounting Style: Connector
Sensing Method: Inductive
Sensing Distance: 15 mm
Output Configuration: NPN/PNP-NO/NC
Supply Voltage - Max: 48 VDC
Supply Voltage - Min: 6 VDC
Operating Supply Current: 300 mA
Operating Supply Voltage: 6 VDC to 48 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 40 C
