Eaton A201122S2025 Standard Barrier 22 POLE A2000 SERIES
ManufacturerEaton(View more products from this manufacturer)
ModelA201122S2025
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Color: Black
Pitch: 0.375 in
Width: 0.65 in
Height: 0.76 in
Length: 9.06 in
Current Rating: 30 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 1 Row
Voltage Rating: 300 V
Wire Gauge Max: 12 AWG
Wire Gauge Min: 22 AWG
Housing Material: Thermoplastic (TP)
Termination Style: Wire Wrap
Flammability Rating: UL 94 V-0
Number of Positions: 22 Position
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
