Channel NO.: 2
Rated input
Power: 400W
Input voltage: 0-150V
Input current: 0-20A×2
CV: 0.1~19.999V/0.1~150.00V
CC: 0~3.000A; 0~20.00A
CR: 0.05Ω~10Ω; 10Ω~7.5kΩ
CP: 0~400W
Battery test function
Voltage range: 0~120V
Discharge capacity: 240Ah
Resolution: 1mA
Test time: 1s~16h
Measuring range:
Voltage readback: 0~19.999V; 0 ~150.00V
Current readback: 0~3.000A; 0~20.00A
Power readback: 400W
Scope of protection: OVP, OCP, OPP, Short circuit
General technical specifications:
Power voltage: 220Vac±10%, optional 110Vac±10%, 45-65hz
Display: 2.8-inch TFT LCD, resolution 320 x 240
Operating temperature: 0 ℃ to 40 ℃
Storage temperature: - 10 ℃ to 70 ℃
Relative humidity: < 80%
Interface: standard USB Device, RS232(or 485)
Size: 90mm * 190mm * 300mm (width * height * depth)
Standard accessories:
One three-core power cord
Two power fuses
1 user manual
Optional accessories:
CD
USB cable
RS232/485 cable
The output line
