EA Elektro-Automatik PUB 12000-40 Programmable Bidirectional DC Power Supply (2000V; 40A; 30KW)

DC output:

Voltage range : 0 - 2000 V

Ripple in CV (rms) : ≤500 mV (BWL 300 kHz)

Ripple in CV (pp) : ≤3000 mV (BWL 20 MHz)

U Min for I Max (sink) : 3.7 V

Current range : 0 - 40 A

Power range : 0 - 30000 W

Resistance range : 1.7 Ω - 2700 Ω

Output capacitance : 50 μF

Effi ciency sink/source (up to) : 96.5% *1

Insulation:

Negative DC pole <-> PE : ±1500 V DC

Positive DC pole <-> PE : +2000 V DC

*1 At 100% power and 100% output voltage; BWLL = band width limit

Datasheet
