EA Elektro-Automatik EA-ELR 10080-170 Programmable Electronic DC loads (80V, 170A, 5000W)

Voltage range: 0 - 80 V

Current range: 0 - 170 A

Power range: 0 - 5000 W

Ripple rms CV: ≤10 mV BW 300 kHz

Ripple and noise p-p CV: ≤100 mV BW 20 MHz

Uₘᵢₙ for Iₘₐₓ (Sink): < 0.5 V

Resistance range: 0.016 Ω - 26 Ω

Output capacity: 7790 µF

Efficiency up to 94.5%

Insulation:

• Negative DC pole <-> PE: ±600 V DC

• Positive DC pole <-> PE: ±600 V DC
