Dwyer VBS-2 Compact Vibration Switch for RMS Monitoring, Adjustable Set Point & Delay (50 mm/s)

Weight: 0.25 lb

Accuracy: ± 3 %

Frequency: 10 to 1000 Hz

Materials: 316 Stainless Steel

Compliance: CE

Time Delay: 1 to 60 s

Switch Type: PNP NO (500 mA max)

Non-Linearity: < ±0.25% of span

Repeatability: < 0.5%

Switch Output: 0 to 50 mm/s

Velocity, Max: 50 mm/s

Velocity, Min: 0 mm/s

Electrical Output: 4 to 20 mA

Electrical Rating: 18 to 32 Vdc

Enclosure Ratings: IP67, NEMA Type 6

Mounting Orientation: Not Position Sensitive

Electrical Connection: M12 4 pin Female

Process Connection Size: 8 mm

Process Connection Type: Metric Male

Operating Temperature, Max: 221 °F

Operating Temperature, Min: -22 °F
