Dwyer TPT-C01 Industrial Pressure Transmitter, 17-4PH SS, High Precision, Sealed Design (Gauge, 100 psi, NPT Male, 1/4 in)

Shock: ± 20 g

Weight: 0.09 kg

Accuracy: ± 1 %

Stability: <± 0.25% FS/year

Vibration: 50 g @ 20 to 2000 Hz

Accuracy Note: ± 1% FS (RMS)

Output Detail: 4 to 20 mA

Output Signal: Current

Pressure Type: Gauge

Pressure, Max: 100 psi

Pressure, Min: 0 psi

Burst Pressure: 3x Full Scale

Proof Pressure: 2x Full Scale

Supply Voltage: 9 to 30 Vdc

Loop Resistance: < 100 Ω

Thermal Effects: Zero Shift: ± 0.01% FS/1°C; Span Error: ± 0.02% FS/1°C

Enclosure Ratings: IP65

Materials, Wetted: 17-4 Stainless Steel

Supply Power Type: DC

Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water

Electrical Connection: Packard 3-pin female

Process Connection Size: 1/4 in

Process Connection Type: NPT Male

Operating Temperature, Max: 185 °F

Operating Temperature, Min: -13 °F

Compensated Temperature, Max: 185 °F

Compensated Temperature, Min: -13 °F
