Dwyer CD-150 Compact Diaphragm Pressure Switch, SPDT, Visible Set Point, Vibration Resistant (Gauge, 150 psi, NPT Female, 1/4 in, None)
ManufacturerDwyer(View more products from this manufacturer)
ModelCD-150
USD 710.70
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Weight: 0.5 lb
Deadband: 14 to 24 psi
Compliance: CE, UL
Switch Type: SPDT Snap
Pressure Type: Gauge
Pressure, Max: 150 psi
Pressure, Min: 10 psi
Switch Rating: 15 A @ 120 Vac, 8 A @ 240 Vac
Pressure Limits: Up to 30 psi
Enclosure Ratings: None
Materials, Wetted: Buna-N (NBR), Steel
Mounting Orientation: Not Position Sensitive
Set Point Adjustment: Internal Screw
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Operating Temperature, Max: 150 °F
Operating Temperature, Min: -30 °F
