Dwyer A1F-O-SS-1-1 OEM Weatherproof Pressure Switch, 316 SS, 15 A for Pumps & Motors (Gauge, 15 psi, NPT Male and Female, 1/2 in x 1/4 in)

Weight: 10.5 oz

Deadband: 2 to 3 psi

Compliance: cULus

Switch Note: 15 A @ 120/240/480 VAC; 1/8 HP @ 125 VAC; 1/4 HP @ 250 VAC.

Switch Type: SPDT Snap

Pressure Type: Gauge

Pressure, Max: 15 psi

Pressure, Min: 2 psi

Switch Rating: 15 A @ 120/240/480 Vac; 1/8 HP @ 125 Vac; 1/4 HP @ 250 Vac

Pressure Limits: Up to 500 psi

Materials, Wetted: 316 Stainless Steel, Fluorocarbon

Media Compatibility: Consult Factory

Mounting Orientation: 20° Off Vertical

Set Point Adjustment: External Cap

Electrical Connection: Screw Terminal

Process Connection Size: 1/2 in x 1/4 in

Process Connection Type: NPT Male and Female

Operating Temperature, Max: 175 °F

Operating Temperature, Min: -40 °F
