Domaille Engineering OS7500P Fiber Optic Laser Cleaver (41°F-86°F, 110-240VAC, 50/60Hz)

Laser Height: 6.6 inches (170 mm)

Laser Width: 8.9 inches (225 mm)

Laser Depth: 21.2 inches (538 mm)

Extract Unit Size: 12.1x11.6x14.4 inches (308x294x366 mm) (LxWxH)

Extract Unit Weight: 37.5 lbs (17 kg)

Power Supply Size: 14.4 x 5 x 3.5 inches (360x127x89mm) (LxWxH)

Power Requirements for Laser: Single Phase, 110-240VAC, 50/60Hz

Power Requirements for Extract Unit: 110-240VAC, 50/60Hz

Laser Cooling: Air Cooled

Extract Unit Capacity: Approx. 1 Million Shards

Machine Weight: 33 lbs (15 kg)

Typical Process Time: 3-4 seconds

Temperature Range: 41°F-86°F (5°C-30°C)

Maximum Altitude: 6500 feet above sea level (1828M)

Maximum Humidity: 20-85% non-condensing

Noise Emission level: Less than 55.0dBA Extract unit measurement at 100%
