Doble 200 S3 DC Micro-Ohmmeter (10 milliohms ~ 5 ohm)

PHYSICAL SPECIFICATIONSDimensions: 18″ W x 7″H x 15″ D (45.7cm x 17.8cm x 38.1cm)

Weight: 19.8 lbs (8.9 Kg)

INPUT POWER: 100 – 240 Vac, 50/60 Hz

RESISTANCE READING RANGE: 10 milliohms at 200A to 5 ohms at 1A

Typical Accuracy: ±(0.15% of reading + 0.15% FS) at test current of 10-200A

TEST CURRENT RANGE: 1 Ampere to 200 Amperes (selectable in 1A steps);

Thermally protected DC power supply.

Datasheet
